Frame: 2012 Time RXR Ulteam

Color: Black, and white

Brake type: Center-Mount rimbrake

Size: Small. 545mm Effective Top Tube. Reach – 390mm. Head tube 149mm. Recommend buyer confirm and research full geometry online.

Condition: No cracks or carbon defects were identified through a thorough visual inspection. The cosmetic imperfections to highlight include: Some scratches on the chainstay shown in pic #7, some scratches on the top tube shown in pic #8, some scratches on the head tube shown in pic #9, some imperfections around the rear brake mounting area, and some road debris wear in the chainstay crown shown in pic #11. We have attempted to show all noticeable imperfections in specific close-up pictures, however other minor imperfections and light signs of use may exist.

Groupset compatibility: Frame can be setup for Di2, EPS, eTap, or mechanical groupsets. This frame was previously setup with an eTap groupset. Other frame/cable stops may be needed for Di2 or mechanical setups.

Bottom bracket: English threaded bottom bracket shell type. No bottom bracket is currently installed or included. We have a handful of lightly used basic bottom brackets on hand, let us know what you need and we can try to ship the frame with the right bottom bracket installed. Additionally, CyclingUpgrades is a Ceramicspeed and Cane Creek Authorized Dealer, if you prefer to have the frame setup with a certain bottom bracket we can add and install it at an additional cost before shipping – message with inquiries/requests.

Steerer length: 75mm of steerer above the top tube. 30mm of spacers below the stem plus the headset cover. We may have an option available to safely extend the steerer tube by 15-18mm – message us for additional details.

Seatpost: Frame specific carbon seatpost included.

Dropout Spacing: QR x 100mm front, QR x 130mm rear.

Weight: 1746 grams as pictured with headset, seatpost, frame hardware, etc.

What’s included: Frame, fork, headset, rear derailleur hanger, seatpost
